Performance Rocketry Nike Smoke 1/4 Rocksim Design File

Download performance_rocketry_nikesmoke4.rkt

To use the design file above, you need a copy of Rocksim, a rocket design and simulation program.

CG: 24.8668 inches from front
CP: 45.2677 inches from front
Margin: 4.66 Overstable

Parts Breakdown

• Performance Rocketry Nike Smoke Nose Cone
• LOC/Precision Conical Transition
• Custom Estes BT 1090 1.0173 inches 25.84 mm 0.7250 inches 18.42 mm 0.7250 inches 18.42 mm 0.9500 inches 24.13 mm 0.9500 inches 24.13 mm 0.2400 inches 6.10 mm 0.0000 inches 0.00 mm 1.5950 inches 40.51 mm 2.5550 inches 64.90 mm 1.8000 inches 45.72 mm 1.5200 Body Tube [Length: 0.00 in]
• Custom Ring
• Custom Estes BT 1090 1.0173 inches 25.84 mm 0.7250 inches 18.42 mm 0.7250 inches 18.42 mm 0.9500 inches 24.13 mm 0.9500 inches 24.13 mm 0.2400 inches 6.10 mm 0.0000 inches 0.00 mm 1.5950 inches 40.51 mm 2.5550 inches 64.90 mm 1.8000 inches 45.72 mm 1.5200 Body Tube [Length: 32.00 in]
• LOC Precision LOC CR-3.9-2.14 Ring
• Custom Estes BT 1090 1.0173 inches 25.84 mm 0.7250 inches 18.42 mm 0.7250 inches 18.42 mm 0.9500 inches 24.13 mm 0.9500 inches 24.13 mm 0.2400 inches 6.10 mm 0.0000 inches 0.00 mm 1.5950 inches 40.51 mm 2.5550 inches 64.90 mm 1.8000 inches 45.72 mm 1.5200 Body Tube [Length: 9.75 in]
• Giant Leap SLIM54 Slimline 54mm Retainer Mass Object
• LOC Precision LOC CR-3.9-2.14 Ring
• Performance Rocketry Nike Smoke Trapezoid Fin Set
• LOC/Precision Rip stop nylon Parachute (57.87 in)
